Tuya Alarm System 3 Lens 3 Screen WiFi IP PTZ Camera Support OEM ODM Security Camera
Product Introduction:
Combining IR and white LED lights, the camera ensures clear vision up to 20 meters, even in complete darkness. The built-in siren can be manually activated or triggered by motion events, emitting a loud alarm to scare off intruders and enhance property protection. This proactive security feature, combined with the camera’s high-resolution night vision, provides round-the-clock surveillance and an immediate response to any security threats, offering both monitoring and active deterrence capabilities.
Features:
● 3-Lens, 2MP + 2MP+ 2MP,
● 3-Screen
● Auto Tracking Motion
● Built-in Siren
● IR Lights + White Lights
● Night vision: Up to 20 meters
● Audio: Two-way Audio
● Support Local SD Card & Cloud Storage
● Power: 5V DC
What's include:
● 1 x Camera
● 1 x Power Cable
● 1 x Adapter
● 1 x Manual
● 1 x Screw bag
Product Supports:
● OEM / ODM Support
● PID Customization
● Giftbox Customized
● Free Logo Printing
Specification Sheet:
| APP |
Tuya / Smart Life |
| Processor: |
XM535D2 |
| Image sensor: |
1/3″ HD CMOS 2 megapixel CMOS sensor(SC2331) |
| Manual video format: |
MP4(1920*3240, storage in mobile) |
| Video compression standard: |
H.264 |
| Video frame rate: |
Max 25 frame |
| Video playback mode: |
Mobile client |
| Audio input and output: |
Input: built in microphone; output: built-in speaker |
| Built in lens-ballhead camera: |
4MM |
| Built in lens-gun camera: |
4MM*2 |
| Focusing method: |
Manual |
| Infrared night vision effect: |
8pcs ir lights,night vision 10 meters,power consumption 1.8W |
| White light effect: |
8 white light lamps, lighting, power consumption 1.8W |
| PTZ control: |
Horizontal rotation 270 degrees vertical 90 degrees |
| Local storage: |
Support MicroSD inserted 128GB card, support 24 hours of video or video alarm |
| Cloud Storage: |
Support |
| Support multiple protocols: |
HTTP,HTPPS,TCP,IPV4,UDP,ICMP,DHCP,DNS,ONVIF |
| Wifi: |
Support IEEE 802.11b/g/n |
| Motion detection: |
Support |
| Video method: |
Continuous video/Event video |
| Alarm action: |
Mobile client push screenshot |
| Firmware upgrade: |
Remote upgrade can be through the network |
| Multi-user sharing: |
Family share to 20 users |
| Supply voltage: |
5V1.5A |
| Working temperature: |
-30 degrees C ~40 C |
| Working environment: |
Outdoor |
| Product size: |
170*145*125MM |
| Packing size: |
198*137*145MM |
| Net weight: |
430g |
| Gross weight/pc: |
530g |
| Carton size: |
72.5*42*46.5CM(30pcs/Carton) |
| Gross weight/carton: |
21Kg(Roughly estimated) |
| Packaging and accessories: |
1 Color box |
| 2 Inner support |
| 3 Screw package |
| 4 Power supply |
| 5 Instructions |
More Information:
The camera supports seamless integration with the Tuya smart platform, enabling you to control and monitor your device through the official Tuya app on your smartphone. The app interface displays the three separate video feeds clearly, making it easy to switch between views, check on your children playing in the yard, monitor the family pet, or keep an eye on the front entrance—all from a single, convenient interface.
The two fixed lenses provide wide, stable panoramic views of key areas like your front yard, driveway, and home entrance, ensuring you can monitor these critical zones continuously without blind spots and capture every detail of the surrounding scene.
The Color Night Vision mode utilizes high-brightness fill lights to illuminate the scene at night, capturing clear and vivid colored footage that allows you to easily distinguish details, identify people, and see every aspect of your property with natural visual clarity.
When the camera identifies a moving target, such as a child playing near the entrance, a visitor approaching the door, or a potential intruder, it will instantly adjust its viewing angle in real time, keeping the moving object centered in the frame and capturing continuous, clear footage of the entire movement.
