8MP 4K Multiple Lens Camera 5Ghz Dual Lens CCTV Camera Outdoor

Basic Information
Brand Name: OEM Brand
Certification: CE, ROHS,EN-18031, UKCA, TELEC, REACH,BSCI
Model Number: WIP-CP800DB
Minimum Order Quantity: One Carton
Get Best Price
Chat Now
Detail Information
Name: Multiple Lens Camera Resolution: 3200*2400
Lens: 3.6MM+8MM Night Vision: Infrared & Color Night Vision
Night Vision Range: Up To 40 Meters Zoom Tracking: Support
Auto Tracking: Support Video Compression Rate: 32Kpbs-8Mpbs
Highlight:

8MP Multiple Lens Camera

,

4K Multiple Lens Camera

,

5Ghz Dual Lens CCTV Camera


Product Description

8MP 4K 5Ghz WiFi Outdoor Dual Lens Surveillance Cctv IP Security Cam Ptz Dome Camera



This outdoor PTZ dome security camera is engineered for premium 4K Ultra HD surveillance, equipped with dual true 8MP image sensors and two high-definition lenses to deliver consistent, sharp 3840×2160 resolution across both viewing channels. No interpolation or pixel stretching—every frame from each lens is genuine 8MP clarity, capturing fine details like faces, license plates and environmental textures with exceptional precision.


Powered by stable 5GHz WiFi for smooth remote streaming, it features flexible pan-tilt-zoom control to eliminate blind spots, IP66 weatherproof rating for year-round outdoor use, smart motion detection, two-way audio, and full-color night vision. The dual-lens design supports simultaneous wide-angle overview and close-up detail monitoring, making it ideal for yards, parking areas, warehouses and commercial premises.


With H.265 compression for efficient storage and reliable app remote access, this true dual 8MP PTZ camera combines high-definition performance, robust connectivity and all-weather durability to provide professional, 24/7 security protection.



Resolution: 8.0Mp+8.0Mp
Lens: 3.6mm+8mm
Auto Zoom Human Tracking
Smart Colorful night vision
Night vision: 25 meters
Local storage: 128G micro SD
Rotation angle: level 0°-350°, vertical 0°-120°
Audio: Two-way Audio
Alarm: push alert to smart phone app
Waterproof: IP65
Mobile App (Android & iOS)
Power: DC12V  (Not Included)



Product Supports:

● OEM / ODM Support

● Giftbox Customized

● Free Logo Printing





Specification

Chipset T41NQ+OV08C10,1/2.8''CMOS
Focal Length 3.6MM+8MM
Resolution 8MP+8MP (3200*2400)
IR Range IR: Up to 40m, White Light: Up to 30m
WIFI version device parameters:
Compression standard Video compression standard h.264/H.265
Video compression rate 32Kpbs-8Mpbs
Audio and video compression algorithm G.711A
Features Audio input and output Built-in pickup and speaker
Memory card Support 8G-128G TF card
Supporting agreement Support TCP/IP,HTTP,TCP,ICMP,UDP,ARP, IGMP,SMTP,FTP,DHCP,DNS,DDNS,NTP,UPNP,RTSP and other protocols
ONVIF Support
Subtitle overlay Support channel name, date and time, superimposed subtitles can be customized by users
Motion Detection 4 independent areas can be set
Communication Interface 1 RJ45 10M/100M Ethernet port
WIFI performance index Wireless standard IEEE802.11b/g/n
Frequency Range 2.4 GHz - 2.4835 GHz-5GGHz
Channel bandwidth Support 20/40MHZ
Safety WPA/WPA2, WPA-PSK/WPA2-PSK, WPS
Transmission distance 20 meters (without obstacles)
AP( hot port) The camera is not connected to the network cable or is in hotspot mode before configuring the wireless function
General specification Stand-by power consumption Less than 8W
Working temperature -10-55
4G version
Network Type FDD-LTE, TDD-LTE, WCDMA/HSPA+, TD-SCDMA, GSM/GPRS/EDGE
Rate LTE FDD/TDD (Cat. 4) 150 Mbps downlink, 50 Mbps uplink
USIM/SIM NANO SIM card
PTZ Parameters
Control speed Horizontal speed 0.01°15°/S, vertical speed 0.01°10°/S
Rotation range 300° horizontal rotation, vertical 0°90° automatic flip
Tracking function Humanoid tracking
Installation method Ceiling mounting and wall mounting
power supply DC12V 1A
Size and Weight
Box Size 145*155*278mm
Quantity for per caron 12pcs/carton
Weight 1kg/pc(Including power adapter)
Weight for per carton 15KG
Carton size 570*452*330mm



This camera features a high-definition dual-lens 8MP+8MP system with intelligent zoom and auto-tracking capabilities.It can automatically detect moving human targets, lock onto them, and zoom in automatically to capture clear details. The camera will steadily follow the moving person in real time, keeping the target in the frame and in focus during the entire zoom process.With the dual-lens design, it ensures stable imaging, smooth zooming, and reliable tracking, greatly enhancing monitoring efficiency and detail recognition for security scenarios.

8MP 4K Multiple Lens Camera 5Ghz Dual Lens CCTV Camera Outdoor 0



This camera is equipped with a high-definition 8MP+8MP dual-lens system and supports three intelligent night vision modes to adapt to different monitoring environments. It features full-color night vision for clear colorful imaging even in low light, infrared black-and-white night vision for invisible monitoring in total darkness, and smart dual-light night vision that automatically switches lighting once detected human motion. Whether day or night, the camera maintains sharp, stable footage, ensuring reliable 24-hour security surveillance.

8MP 4K Multiple Lens Camera 5Ghz Dual Lens CCTV Camera Outdoor 1
