Detail Information

Name:	Home Doorbell Camera	Resolution:	2Mp & 5Mp Optional
WiFi:	2.4GHz	Battery:	2pcs 18650 Battery, Tatal 5200mAh
Power Supply:	Battery Powered	Meterial:	ABS
Audio:	Built In MIC & Speaker	Night Vision:	Infrared Night Vision
Chime:	Optianal
Highlight:	2MP Home Doorbell Camera , Wide Angle Video Doorbell Security Camera , Video Doorbell Security Camera IP65

Product Description

Tuya 2MP Doorbell Camera with 170° Wide Angle IP65 Waterproof Home Security Video Doorbell

Features:

● Viewing angle: 170°
● Maximum image size: 1920 X 1080
● 1/3-inch 2-megapixel CMOS image sensor
● IR Night Vision: 4* 5mm 850nm LED
● Power consumption: standby current 15uA, working current 200mA
● Two-way audio
● Support SD card (Max. 128G), cloud storage
● Communication protocol: TCP/IP, HTTP, DHCP, DNS
● Wifi: Support 2.4G WIFI IEEE802.11b/g
● APP:Tuya Smart
● Power supply: built-in 2600mAh (two) battery and external MICRO USB 5V 2A and AC/DC 12-24V/1A
● Waterproof IP55
● Support PIR Motion Detection
● Support Google, Alexa

Package Included:

● Doorbell Camera *1

● Doorbell Chime (Optional) *1

● 2600mAh Battery (Optional) *2

● User Manual *1

● Installation Accessories

Product Supports:

● OEM / ODM Support

● PID Customization

● Giftbox Customized

● Free Logo Printing

Specification

Model No.		WIP-TR200SB
APP		Tuya
Image Sensor	Sensor	1/3" color CMOS Sensor, RTL8715+F37
	Viewing Angle	130°
	Minimum Illumination	0.01 Lux
Audio	Input/Output	Two-way voice intercom available (built-in Microphone and speaker)
Video	Video Compressing Method	H.265 (support H.264, H.265)
	Image Frame Rate	1/25~1/100,000 per second
	Maximum Image Resolution	1920*1080P
	Light Source for Night Vision	IRCUT double optical filter automatic switching, and 4pcs 850nm LED Light IR Distance: 7M
Network	Wireless Network	2.4G Wi-Fi (IEEE802.11b/g/n)
	Protocol Supported	TCP/IP, HTTP, DHCP, DNS
Alarm Notification	Alarm Methods	Alarm push by mobile APP
Wake-up	Wake-up Method	PIR motion detection wake-up, ringing doorbell wake-up, remote APP live wake-up
Video Recording	Recording Method	Alarm triggered recording and manual recording
	Video Storage	Cloud & local Micro SD card storage (max. 128G)
Battery	Capacity	2*18650 battery, 5200mAh
	Removability	Removable
	Battery Life	Around 3 months (If trigger 20 times everyday)
	Standby Time	1 year
	Charging Voltage	DC5V/2A (USB-Type C Port)
	Charge Time	< 8 hours
Power Consumption	Working Current	200mA
	Standby Current	1.5mA
Interfaces	Power Supply	1 USB-Type C Port
	SD Card	1 Micro SD card (up to 128GB supported)
	Button	1 Reset button, 1 Doorbell Button
Power Supply	Power Supply	AC12-24V/DC12-24V (optional)
Installation Method	Installation Method	Screw installation & Double-sided tape installation
Environment	Dustproof and waterproof	IP65
	Operating Environment	-20° ~ 50°C / less than 90% (no condensation)
Specification	Size (LxWxH)	6138135mm
	Material + Process	PC+ABS
	Color	White/Grey/Black
Door Chime Spec.	Working Frequency	433Mhz
	Receiveing Range	150M (open space)
	Ringtones	58 for choosen
	Volume	4 grade volume adjusting, 25dB ~ 85dB
	Power Supply	DC5V, 1A (by micro usb port)
	LED Night	* Flash blue light when doorbell ringing * White light work as a PIR night light in the night
	Material + Process	ABS

More Information:

Tuya 2MP smart video doorbell camera with 1080P full HD video, two‑way audio, infrared night vision, and PIR motion detection. It connects to 2.4G Wi‑Fi and works with the Tuya / Smart Life app for real‑time viewing, instant alerts, and remote intercom. It supports wide‑angle viewing, weatherproof outdoor use, local TF card recording, and smart home compatibility. A reliable wireless solution for home security and door monitoring.

2MP Home Doorbell Camera 170 Degree Wide Angle Video Doorbell Security Camera IP65 Waterproof 0

This doorbell camera is specially designed for outdoor use. It features an IP65 weatherproof rating, providing reliable protection against dust, rain, and other outdoor elements. Additionally, it comes with a built-in rain cover that offers extra shielding, ensuring stable performance and long-term durability even in harsh weather conditions.

2MP Home Doorbell Camera 170 Degree Wide Angle Video Doorbell Security Camera IP65 Waterproof 1

Powered by a built-in 5200mAh rechargeable battery, this wireless doorbell camera delivers up to 40 days of battery life under laboratory conditions with approximately 20 daily triggers. Actual battery performance may vary depending on environmental factors, usage frequency, and operating conditions.

2MP Home Doorbell Camera 170 Degree Wide Angle Video Doorbell Security Camera IP65 Waterproof 2

Tag:

Place of Origin:	China
Brand Name:	OEM Brand
Certification:	CE, ROHS, BSCI, UKCA, EN-18031, TELEC, REACH
Model Number:	WIP-TR200SB

Minimum Order Quantity:	One Carton

2MP Home Doorbell Camera 170 Degree Wide Angle Video Doorbell Security Camera IP65 Waterproof
